Tata Ace Gold Diesel

Ace Gold Diesel BS6 Phase 2 comes with a turbocharged 2 cylinder 702 CC engine delivering 16.17 kW (22HP) max power & a max torque of 55 Nm. This enhanced power & pickup ensures 32% improved acceleration vis a vis the BS6 Phase 1 variant. The vehicle is now offered with a Direct Drive gearbox, offering superior drivability, enhanced comfort and improved fuel efficiency. Ace known for its high loadability, low maintenance and high Fuel Efficiency also comes with an upgraded Cabin providing enhanced Safety, High Comfort and Superior Drivability for maximum productivity performance. Ace Gold Diesel is suitable for customers looking for a vehicle with high loadability and high performance.

1835

GVW

30 L

Fuel Tank Capacity

702 CC

Engine

Download Brochure

Overview
Specifications
Gallery

Earn More with Better Mileage and Better Pickup

Bigger Head Lamp with 5X Improved illumination intensity
Improved Focus Range for safe night and early morning driving

New Direct Drive Gear Box with improved drivability, improved fuel efficiency and low NVH
New steering box with 35% reduced steering effort

Ergonomic seats with Head Rest and extra rear ward travel for ergonomic driving.
Pendular APM module for better driving experience

A 2 cylinder 702cc Turbo charged Inter cooled engine offering higher Power & Pick up
High Power of 16.17 kW (Power Mode) and 12.5 kW (City Mode)
High Torque of 55 Nm (Power Mode) and 40 Nm (City Mode)
32% improvement in acceleration (0-60 kmph)

New Direct Drive Gear Box offering upto 5% higher Mileage

Easily serviceable Engine
Long Service Intervals
2 year/72000 km warranty

Engine

Type	4 Stroke, Turbocharged InterCooled, Direct Injection Common Rail Diesel engine
Power	Power Mode : 16.17 kW (22 HP) @ 3600 +/-100 rpm City Mode : 12.5 kW at 3600 +/-100 rpm
Torque	Power Mode : 55 Nm @ 1800 to 2200 engine rpm; City Mode : 40 Nm @1800 to 2200 engine rpm
Gradeability	35 % (Power Mode)

Clutch and Transmission

Gear Box Type	GBS G65-5/6.31
Steering	Manual Steering System 27.9-30.4(Variable); 380 mm Dia
Max Speed	65 kmph

Brakes

Brakes	Front - Disc brakes; Rear - Drum brakes
Suspension Front	Rigid Axle with Parabolic Leaf Spring
Suspension Rear	Live Axle with Semi-elliptical Leaf Spring
