Tata Ace Gold Diesel

Ace Gold Diesel BS6 Phase 2 comes with a turbocharged 2 cylinder 702 CC engine delivering 16.17 kW (22HP) max power & a max torque of 55 Nm. This enhanced power & pickup ensures 32% improved acceleration vis a vis the BS6 Phase 1 variant. The vehicle is now offered with a Direct Drive gearbox, offering superior drivability, enhanced comfort and improved fuel efficiency.

1835

জিডব্লিউভি

30 L

ফুৱেল টেংকৰ ক্ষমতা

702 CC

ইঞ্জিন

Download Brochure

Step into the future of last-mile
delivery with the Tata Ace Pro

Step into the future of last-mile delivery with the Tata Ace Pro

অৱলোকন
বৈশিষ্ট্য
গেলেৰী

অধিক মাইলেজ আৰু অধিক পিকআপৰ যোগেদি অধিক উপাৰ্জন কৰক

Bigger Head Lamp with 5X Improved illumination intensity
Improved Focus Range for safe night and early morning driving

New Direct Drive Gear Box with improved drivability, improved fuel efficiency and low NVH
New steering box with 35% reduced steering effort

Ergonomic seats with Head Rest and extra rear ward travel for ergonomic driving.
Pendular APM module for better driving experience

A 2 cylinder 702cc Turbo charged Inter cooled engine offering higher Power & Pick up
High Power of 16.17 kW (Power Mode) and 12.5 kW (City Mode)
High Torque of 55 Nm (Power Mode) and 40 Nm (City Mode)
32% improvement in acceleration (0-60 kmph)

New Direct Drive Gear Box offering upto 5% higher Mileage

Easily serviceable Engine
Long Service Intervals
2 year/72000 km warranty

ইঞ্জিন

প্ৰকাৰ	4 Stroke, Turbocharged InterCooled, Direct Injection Common Rail Diesel engine
পাৱাৰ	Power Mode : 16.17 kW (22 HP) @ 3600 +/-100 rpm City Mode : 12.5 kW at 3600 +/-100 rpm
টৰ্ক	Power Mode : 55 Nm @ 1800 to 2200 engine rpm; City Mode : 40 Nm @1800 to 2200 engine rpm
গ্ৰেডেবিলিটি	35 % (Power Mode)

ক্লাচ্চ আৰু ট্ৰান্সমিশ্যন

গীয়েৰ বক্সৰ প্ৰকাৰ	GBS G65-5/6.31
ষ্টীয়েৰিং	Manual Steering System 27.9-30.4(Variable); 380 mm Dia
সৰ্বাধিক স্পীড	65 kmph

ব্ৰেকসমূহ

ব্ৰেকসমূহ	Front - Disc brakes; Rear - Drum brakes
ৰিজেনেৰেটিভ ব্ৰেক	-
ছাছপেন্সন ফ্ৰণ্ট	Rigid Axle with Parabolic Leaf Spring
ছাছপেন্সন ৰীয়েৰ	Live Axle with Semi-elliptical Leaf Spring

হুইল আৰু টায়াৰসমূহ

টায়াৰসমূহ	145 R12 LT 8PR RADIAL (Tubeless Type)

বাহনৰ আকাৰ (মিঃমিঃ)

দীঘ	3800
প্ৰস্থ	1500
উচ্চতা	1845
হুইলবেছ	2100
ফ্ৰণ্ট ট্ৰেক	1300
ৰীয়েৰ ট্ৰেক	1320
গ্ৰাউণ্ড ক্লীয়েৰেন্স	160
ন্যূনতম টিচিআৰ	4300

ওজন (কিঃগ্ৰাঃ)

জিভিডব্লিউ	1835
পেলোড	CLB:900 \| High Deck:815

বেটাৰী

বেটাৰী ৰসায়ন	-
বেটাৰীৰ শক্তি (kWh)	-
আইপি ৰেটিং	-
প্ৰমাণিত ৰেঞ্জ	-
মন্থৰ চাৰ্জিং সময়	-
দ্ৰুত চাৰ্জিং সময়	-
